👋Welcome to Streamlit Book

This book contains the details of the python package called streamlit and its concepts, Visit streamlit for more details.

Introduction

What is streamlit?
How to install?

Concepts

Title, input, text input, image, video, sidebar, markdown, latex ..etc

References

docs

Introduction

Streamlit is a python library that makes easy to create and share the web applications with out html, css and javascript.

1. Pre-requisites

Python Version > 3.6

2. Installation

Standalone🎷
- pip install streamlit
- streamlit hello
Anaconda🐍
- conda create --name streamlit (create new environment)
- conda activate streamlit (activate)
- pip install streamlit
- streamlit hello
- conda deactivate (to deactivate )
Venv ✅(Built in python no need to do pip install)
- python -m venv streamlit (create new environment)
- cd pathtostreamlit\Scripts\activate.bat (activate)
- pip install streamlit
- streamlit hello
- cd pathtostreamlit\Scripts\deactivate.bat (deactivate)
Virtualenv👋
- pip install virtualenv
- virtual streamlit (create new environment)
- cd pathtostreamlit\Scripts\activate.bat (activate)
- pip install streamlit
- streamlit hello
- cd pathtostreamlit\Scripts\deactivate.bat (deactivate)
Pipenv🔆
- pip install pipenv
- pipenv install streamlit
- pipenv shell or pipenv run (activate)
- streamlit hello
- exit (deactivate)

3. Uninstallation

pip uninstall streamlit

4. Commands

Basic Commands✅
- streamlit --help
- streamlit hello
- streamlit config show
- streamlit cache clear
- streamlit docs
- streamlit --version
Run Command👋
- streamlit run scriptname.py
- streamlit run 'url.py' (Github or Gist)
  - Gist Example - streamlit run https://gist.github.com/SurendraRedd/feaa6f29961501fa9fce7a45abc14651/raw/Example.py
  - GitHub Example - streamlit run https://github.com/SurendraRedd/StreamlitProjects/blob/master/Example.py
- streamlit run app.py --server.port 8503 (to run in different port)

Concepts

Import

import streamlit as st

Display

Text/Title

  import streamlit as st
  st.title("Welcome to streamlit")
  st.text('Happy Learning!')

Header/Subheader

  import streamlit as st
  st.header('Header')
  st.subheader('Subheader')

Markdown

  import streamlit as st

  # Basic markdown
  st.markdown('Header')

  # Advanced
  html_temp = """
  <div style="background-color:tomato;padding:10px">
  <h2 style="color:white;text-align:center;">Markdown html Example </h2>
  </div>
  """
  st.markdown(html_temp,unsafe_allow_html=True)
  st.markdown('<i class="material-icons">{}</i>'.format("people"), unsafe_allow_html=True)

  # Load stylesheet
  with open(style.css) as f:
  	st.markdown('<style>{}</style>'.format(f.read()), unsafe_allow_html=True)

Latex

  import streamlit as st
  st.latex(r''' e^{i\pi} + 1 = 0 ''')
  st.latex(r'''
  		... a + ar + a r^2 + a r^3 + \cdots + a r^{n-1} =
  		... \sum_{k=0}^{n-1} ar^k =
  		... a \left(\frac{1-r^{n}}{1-r}\right)
  		... ''')

Write

  import streamlit as st
  st.write('Example text')
  st.write(['st', 'is <', 3])
  st.write("✔️ Time up!")

Code

  import streamlit as st
  st.code('s="Happy Learning!" for i in range(0,10): print(s)')

  st.echo()
  with st.echo():
  	text = 's="Happy Learning!" for i in range(0,10): print(s)'
  	st.write(text)

Help

  import streamlit as st
  st.help(range)

Data

	import streamlit as st
	import pandas as pd
	import numpy as np

	df1 = pd.DataFrame(
    np.random.randn(50, 5),
    columns=('col %d' % i for i in range(5)))
	my_table = st.table(df1)

	st.write('Dataframe example')
	st.dataframe(df1)

	data = {'1':"True",'2':"True",'3':"False"}
	st.json(data)

Media

	import streamlit as st
	from PIL import Image
	import urllib.request

	# Basic image
	st.image('./image.png')

	img = Image.open("download.jfif") #open the image stored in specified location

	#Opens the image from the url
	img = Image.open(urllib.request.urlopen("https://mms.businesswire.com/media/20200616005364/en/798639/22/Streamlit_Logo_%281%29.jpg"))

	st.image(img, width=300, caption="Simple Image")


	# Video playing
	vid_file = open("videofile.mp4","rb").read() #play the video stored in specified location
	st.video(vid_file)

	#Audio
	audio_file = open('myaudio.ogg', 'rb')
	audio_bytes = audio_file.read()
	st.audio(audio_bytes, format='audio/ogg')

Charts

	import streamlit as st
	import numpy as np
	import matplotlib.pyplot as plt

	st.line_chart({"data": [1, 5, 2, 6, 2, 1]})
	st.area_chart({"data": [1, 5, 2, 6, 2, 1]})
	st.bar_chart({"data": [1, 5, 2, 6, 2, 1]})

	arr = np.random.normal(1, 1, size=100)
	fig, ax = plt.subplots()
	ax.hist(arr, bins=20)
	st.pyplot(fig)

	st.altair_chart(data)
	st.vega_lite_chart(data)
	st.plotly_chart(data)
	st.bokeh_chart(data)
	st.pydeck_chart(data)
	st.deck_gl_chart(data)
	st.graphviz_chart(data)
	st.map(data)

Widgets

	import streamlit as st

	st.button('Click')
	st.checkbox('Check the checkbox')
	st.radio('Radio Button',[1,2,3])
	st.selectbox('Select', [1,2,3])
	st.multiselect('Multiselect', [1,2,3])
	st.slider('slide',min_value=0, max_value=10)
	st.text_input('Enter Username')
	st.number_input('Enter a Number')
	st.text_area('Enter Text Here!')
	st.date_input('Date Input')
	st.time_input('Time entry')
	st.file_uploader('File Uploader')
	st.beta_color_picker('Select color')

Sidebar

	import streamlit as st
	st.sidebar.<widget>
	<widget> : button, checkbox, radio, selectbox, multiselect, slider, text_input, number_input, text_area, date_input, time_input

Control Flow

	import streamlit as st
	st.stop()

Progress Bar

	import streamlit as st
	import time

	# Sample Progress bar
	my_bar = st.progress(0)

	for percent_complete in range(100):
		time.sleep(0.1)
		my_bar.progress(percent_complete + 1)

	with st.spinner('Wait for it...'):
	    time.sleep(5)
	st.write('Done!')

Status Messages & Others

	import streamlit as st

	st.error('Error Message')
	st.warning('Warning Message')
	st.info('Info Message')
	st.success('Success Message')
	st.exception("IndexError('list out of index')")
	st.balloons()

	st.empty()
	place_holder = st.empty()
	place_holder.text('Replaced!)

	st.get_option(key)
	st.set_option(key)

	st.beta_set_page_config(layout='wide')

Cache or Optimize

	import streamlit as st

	@st.cache
	func()

Magic Command

	import streamlit as st

	'''
	# Markdown magic

	This is some _**text**_.
	'''

	df = pd.DataFrame({'col1': [40,54,67]})
	df  # <-- df values

	x = 100
	'x', x  # <-- 'x' and its value

Apps Deployment

Using StreamlitShare

Prerequisites
- Requirements.txt file - Github account - Access to share.streamlit.io
- ReferLink
Using Heroku

References

docs/API

Streamlit Sample codes

Codes

Example- Usage of Slider, SelectBox & Miltiselect

  import streamlit as st
  import numpy as np

  x = st.slider('Select a value')
  st.write(x, 'squared value is', x * x)

  Exp = streamlit.selectbox("Choose your Experience: ", np.arange(1, 40, 1))

  lan = st.multiselect("Which is your favorite language?",
                   ["Python", "JavaScript",
                   "Java", "C", "Julia"])

Example- Usage of dataframe

  import pandas as pd
  import streamlit as st

  @st.cache
  def load_data():
      df = pd.read_csv("data.csv") # csv
      #df = pd.read_excel("data.excel") #excel
      return df

  # Will only run once if already cached
  df = load_data()

Example- Jupyter Notebook

  # Run jupyter notebook in streamlit using 3 steps below
  - jupyter nbconvert --to script scriptname.ipynb
  - awk '!/ipython/' scriptname.py > [temp.py](http://temp.py/) && mv [temp.py](http://temp.py/) [app.py](http://app.py/) && rm scriptname.py
  - streamlit run [app.py](http://app.py/)
  Refer the blog more details https://learnups2020.wordpress.com/2020/11/07/streamlit-code-running-from-jupyter-notebook/

Example- Altair Chart

  # Alt Chart example
  import pandas as pd
  import numpy as np
  import altair as alt
  import streamlit as st

  df = pd.DataFrame(np.random.randn(100, 3), columns=['a', 'b', 'c'])
  c = alt.Chart(df).mark_circle().encode(x='a', y='b', size='c',
                                  color='c')
  st.altair_chart(c, width=-1)

Example- Simple Calculator App using sqlite DB

  # Simple Calculator
  import pandas as pd
  from pathlib import Path
  import sqlite3
  from sqlite3 import Connection
  import streamlit as st

  URI_SQLITE_DB = "test.db"


  def main():
  st.title("Simple Calculator")
  st.markdown("Select two inputs from sidebar.")

  conn = get_connection(URI_SQLITE_DB)
  init_db(conn)

  build_sidebar(conn)
  display_data(conn)
  run_calculator(conn)


  def init_db(conn: Connection):
          conn.execute(
                  """CREATE TABLE IF NOT EXISTS test
                  (
                          INPUT1 INT,
                          INPUT2 INT
                  );"""
          )
          conn.commit()


  def build_sidebar(conn: Connection):
          st.sidebar.header("Inputs")
          input1 = st.sidebar.slider("value-1", 0, 100)
          input2 = st.sidebar.slider("value-2", 0, 100)
          if st.sidebar.button("Save to database"):
                  conn.execute(f"INSERT INTO test (INPUT1, INPUT2) VALUES ({input1}, {input2})")
                  conn.commit()


  def display_data(conn: Connection):
          if st.checkbox("Display data from the database"):
                  st.dataframe(get_data(conn))


  def run_calculator(conn: Connection):
          if st.button("Calculate Sum"):
                  st.info("Sum of two inputs function is called.")
                  df = get_data(conn)
                  st.write(df.sum())


  def get_data(conn: Connection):
          df = pd.read_sql("SELECT * FROM test", con=conn)
          return df


  @st.cache(hash_funcs={Connection: id})
  def get_connection(path: str):
          """Put the connection in cache to reuse if path does not change between Streamlit reruns.
          NB : https://stackoverflow.com/questions/48218065/programmingerror-sqlite-objects-created-in-a-thread-can-only-be-used-in-that-sa
          """
          return sqlite3.connect(path, check_same_thread=False)


  if __name__ == "__main__":
          main()

Example- ProgressBar in sidebar and generate chart

  import streamlit as st
  import time
  import numpy as np

  progress_bar = st.sidebar.progress(0)
  status_text = st.sidebar.empty()
  last_rows = np.random.randn(1, 1)
  chart = st.line_chart(last_rows)


  for i in range(1, 101):
  new_rows = last_rows[-1, :] + np.random.randn(5, 1).cumsum(axis=0)
  status_text.text("%i%% Complete" % i)
  chart.add_rows(new_rows)
  progress_bar.progress(i)
  last_rows = new_rows
  time.sleep(0.05)

  progress_bar.empty()

  st.button("Re-run")

Example- Streamlit Components Example

  import streamlit as st

  st.sidebar.subheader("Component 1")

  t1 = st.sidebar.text_input("Component 1 name")
  s1 = st.sidebar.slider("Component 1 value")

  st.sidebar.markdown("---")

  st.sidebar.subheader("Component 2")
  t2 = st.sidebar.text_input("Component 2 name")
  s2 = st.sidebar.slider("Component 2")

  st.title("Hello!")

  st.write(t1, s1)
  st.write(t2, s2)


  template = """
  <div class="markdown-text-container stText" style="width: 698px;">
  <div style="font-size: small;">This is paragraph 1 text.</div>
  <p>This is paragraph 2 text.</p>
  <p>This is paragraph 3 text.</p>
  </div>
  """

Example- Streamlit Code Share Example

  Prerequisites
  - pip install streamlit-embedcode
  import streamlit as st
  from streamlit_embedcode import github_gist, gitlab_snippet, pastebin_snippet, codepen_snippet, ideone_snippet, tagmycode_snippet

  st.title("Github Gist Snippet")
  github_gist("https://gist.github.com/SurendraRedd/feaa6f29961501fa9fce7a45abc14651")

  st.title("Gitlab Snippet")
  gitlab_snippet("https://gitlab.com/snippets/2037642", height=400)

  st.title("Pastebin Snippet")
  pastebin_snippet("https://pastebin.com/Ryr8q1kq", width = 600, scrolling = False)

  st.title("Code Pen Snippet")
  codepen_snippet("https://codepen.io/surendra1985/pen/wvGREBb", width = 600, scrolling = False)

  st.title("Ideone Snippet")
  ideone_snippet("https://ideone.com/tXCake")

  st.title("Tagmycode Snippet")
  tagmycode_snippet("https://tagmycode.com/snippet/14517/streamlit-basic-concepts#.X6fD8WgzZPY")

Data Applications

Codes

Simple CRUD Application

  import streamlit as st
  import pandas as pd
  import base64
  from PIL import Image
  import json
  import urllib.request

  # DB Management
  # DB Functions

  # Database Creation & Connection
  import sqlite3
  from sqlite3 import Connection
  import streamlit as st

  # Security
  #passlib,hashlib,bcrypt,scrypt

  import hashlib

  URI_SQLITE_DB = "Users.db"

      html_temp = """
          <body style="background-color:red;">
          <div style="background-color:tomato;padding:10px">
          <h2 style="color:white;text-align:center;">Simple Login Application Code</h2>
          </div>
          </body>
      """
  st.set_page_config(
  page_title = 'Apps',
  page_icon = "✌",
  layout = "centered",
  initial_sidebar_state = "expanded"
  )

  def make_hashes(password):
      return hashlib.sha256(str.encode(password)).hexdigest()

  def check_hashes(password,hashed_text):
      if make_hashes(password) == hashed_text:
          return hashed_text
      return False

  # """
  # check_same_thread = False is added to avoid same thread issue
  # """
  conn = sqlite3.connect(URI_SQLITE_DB, check_same_thread=False)
  c = conn.cursor()

  @st.cache(hash_funcs={Connection: id})
  def get_connection(path: str):
      """Put the connection in cache to reuse if path does not change between Streamlit reruns.
      NB : https://stackoverflow.com/questions/48218065/programmingerror-sqlite-objects-created-in-a-thread-can-only-be-used-in-that-sa
      """
      return sqlite3.connect(path, check_same_thread=False)

  def create_usertable(conn: Connection):
      c.execute('CREATE TABLE IF NOT EXISTS userstable(username TEXT PRIMARY KEY,password TEXT)')

  def add_userdata(conn: Connection,username,password):
      c.execute('INSERT INTO userstable(username,password) VALUES (?,?)',(username,password))
      conn.commit()

  def login_user(conn: Connection,username,password):
      c.execute('SELECT * FROM userstable WHERE username =? AND password = ?',(username,password))
      data = c.fetchall()
      return data

  def main():

      """Simple Login Application"""
      st.markdown(html_temp, unsafe_allow_html=True)
      menu = ["Home","Login","SignUp","Others","About"]
      st.markdown(
      """
      <style>
      .sidebar .sidebar-content {
          # background-image: linear-gradient(#264D59, #43978D, #F9E07F, #F9AD6A, #D46C4E);
          background-image: linear-gradient(to right top, #ebe9f3, #b7bdcc, #8094a5, #496e7c, #0c4950);
          color: blue;
      }
      </style>
      """,
          unsafe_allow_html=True,
      )

      choice = st.sidebar.selectbox("Menu", menu)


      if choice == "Home":
          st.subheader("Home Page:")

      elif choice == "Login":
          st.subheader("**Please Login to the page !**")
          username = st.sidebar.text_input("Username","")
          password = st.sidebar.text_input("Password",type='password')

      if st.sidebar.checkbox("Login"):
          hashed_pswd = make_hashes(password)
          result = login_user(conn,username,check_hashes(password,hashed_pswd))
          if result:
          st.success("Logged In as {0!s}".format(username))
          else:
          st.warning("Incorrect Adhar/Passport/VoterID/Password")

      elif choice == "SignUp":
          st.subheader("Create New Account")
          new_user = st.text_input("Username","")
          new_password = st.text_input("Password",type='password')

      if st.button("Signup"):
          create_usertable(conn)
          add_userdata(conn,new_user,make_hashes(new_password))
          st.success("Account created successfully. Please Login to application.")

      elif choice == "Others":
          st.info("Please visit to nearest adhar or passport or voterid location to get any of the ID.")

      elif choice == "About":
          st.sidebar.title("App Version details")
          st.sidebar.info("**App version 1.0**")


  if __name__ == "__main__":
      main()

PencilSketcher App

  import streamlit as st
  import numpy as np
  from PIL import Image
  import cv2

  st.set_option('deprecation.showfileUploaderEncoding', False)

  def dodgeV2(x, y):
      return cv2.divide(x, 255 - y, scale=256)

  def pencilsketch(inp_img):
      img_gray = cv2.cvtColor(inp_img, cv2.COLOR_BGR2GRAY)
      img_invert = cv2.bitwise_not(img_gray)
      img_smoothing = cv2.GaussianBlur(img_invert, (21, 21),sigmaX=0, sigmaY=0)
      final_img = dodgeV2(img_gray, img_smoothing)
      return(final_img)


  st.title("PencilSketcher App")
  st.write("This Web App is to help convert your photos to realistic Pencil Sketches")

  file_image = st.sidebar.file_uploader("Upload your Photos", type=['jpeg','jpg','png'])

  if file_image is None:
      st.write("You haven't uploaded any image file")

  else:
      input_img = Image.open(file_image)
      final_sketch = pencilsketch(np.array(input_img))
      st.write("**Input Photo**")
      st.image(input_img, use_column_width=True)
      st.write("**Output Pencil Sketch**")
      st.image(final_sketch, use_column_width=True)

IrisPrediction App

  import streamlit as st
  import pandas as pd
  from sklearn import datasets
  from sklearn.ensemble import RandomForestClassifier
  import urllib.request
  from PIL import Image

  html_temp = """
      <body style="background-color:red;">
      <div style="background-color:tomato;padding:10px">
      <h2 style="color:white;text-align:center;"> Classifier(SL) - Iris Flower Prediction App</h2>
      </div>
      </body>
  """

  st.beta_set_page_config(
          page_title = 'Iris',
          page_icon = "🌺",
          layout = "centered",
          initial_sidebar_state = "expanded"
      )

  def inputFeatures():
      sepal_length = st.sidebar.slider('Sepal length', 4.3, 7.9, 5.4)
      sepal_width = st.sidebar.slider('Sepal width', 2.0, 4.4, 3.4)
      petal_length = st.sidebar.slider('Petal length', 1.0, 6.9, 1.3)
      petal_width = st.sidebar.slider('Petal width', 0.1, 2.5, 0.2)
      data = {'sepal_length': sepal_length,
              'sepal_width': sepal_width,
              'petal_length': petal_length,
              'petal_width': petal_width}
      features = pd.DataFrame(data, index=[0])
      return features

  def main():
      st.markdown(html_temp, unsafe_allow_html=True)
      st.sidebar.info("""
          ## Packages:
          - Streamlit, pandas & sklearn
          - How to install?
          > 1. **pip install streamlit**
          > 2. **pip install pandas**
          > 3. **pip install scikit-learn**
          """)
      st.sidebar.header('Input Features')
      df = inputFeatures()

      st.sidebar.info("#### Iris Flower species : setosa, versicolor, virginica")
      img = Image.open(urllib.request.urlopen("https://raw.githubusercontent.com/SurendraRedd/MachineLearningCode/master/Iris_Species.png")) # Opens the image from the url
      st.sidebar.image(img, width=300, caption="")
      st.sidebar.info("#### Features : setosa, versicolor, virginica")
      img = Image.open(urllib.request.urlopen("https://raw.githubusercontent.com/SurendraRedd/MachineLearningCode/master/features.png")) # Opens the image from the url
      st.sidebar.image(img, width=400, caption="")

      st.subheader('Input Features')
      st.write(df)

      iris = datasets.load_iris()
      X = iris.data
      Y = iris.target

      clf = RandomForestClassifier()
      clf.fit(X, Y)

      prediction = clf.predict(df)
      prediction_proba = clf.predict_proba(df)

      st.subheader('labels & index number')
      st.write(iris.target_names)

      st.subheader('Prediction')
      st.write(iris.target_names[prediction])
      #st.write(prediction)

      st.subheader('Prediction Probability')
      st.write(prediction_proba)




  if __name__ == '__main__':
      main()

Streamlit Digital Book

👋Welcome to Streamlit Book

Introduction

Concepts

References

Introduction

1. Pre-requisites

2. Installation

3. Uninstallation

4. Commands

Concepts

Import

Display

Data

Media

Charts

Widgets

Sidebar

Control Flow

Progress Bar

Status Messages & Others

Cache or Optimize

Magic Command

Apps Deployment

References

Streamlit Sample codes

Codes

Data Applications

Codes

References

HappyLearning!

Contributors
